SIUI SR-8210 - 6.6 Li-ion Battery

Use and Operation
6-16
Fig. 6-7 USB port on the back cover
If the kV digital tube displays "888" when the update fails, check the USB disk to see if it
contains the update program, and if the name of the update program is correct. After
confirming the above, repeat the above steps and wait for the system to finish the
automatic update. If the update failure still occurs, try to replace the USB disk and perform
the update operation again. If a few replacements of USB disk do not work, please contact
the technical person to fix the issue.
When a system error occurs, the error code will be displayed on the kV display window of
the console. The corresponding content and processing of the error code are described in
Table 7-1 Failure Description and Analysis.
【Caution】
If the display on the control panel is in disorder, the display
parameters go beyond normal range, or any other unpredictable
abnormal situation occurs, DO NOT perform any operation. Cut off
the power supply of the main unit immediately. Restart the device
after 1
minute, and the device may return to normal usually. If the
display disorder still exists, contact the factory for service.
6.6 Li-ion Battery
6.6.1 Removal and Installation of Li-ion Battery
Place the portable X-ray machine upside down. The lithium-ion battery is as shown in Fig.
6-8. Pull out the pick piece below the device and pull it out in the arrow direction, and the
battery can be removed as indicated in Fig. 6-9. The battery can be charged separately or
be charged on the portable X-ray machine. To install the battery back into the device,
simply snap the battery back till being locked by the pick piece.
