CONTROLS, INSTRUMENTS AND EQUIPMENT
106
3. Insert the rear end hooks of the upper body module into
the slots in the console.
Note: Make sure the air intake duct is positioned correctly in
the boot.
4. Tighten air intake duct clamp.
5. On both sides, install the upper body module retaining
screws.
Tightening Torque
Upper body screws
1.8 ± 0.2 Nm
(16 ± 2 lbf-in)
6. Connect the manifold air pressure and temperature sen-
sor (MAPTS) connector.
7. Connect the headlight connectors.
8. Install the storage compartment but leave the cover
open.
9. Install gauge, secure with the screws.
Tightening Torque
Gauge screws
2.3 ± 0.2 Nm
(20 ± 2 lbf-in)
18) Side Panels
WARNING
Never operate engine with side panels opened or removed
from vehicle.
