Drive Belt Installation
1. If necessary, open the driven pulley, refer to DRIVE BELT
REMOVAL above.
2. Slip the belt over the drive pulley, then over the driven
pulley.
NOTICE Do not force or use tools to pry the belt into place,
as this could cut or break the cords in the belt.
Note: The maximum drive belt life span is obtained when belt
is installed with arrows in the direction of rotation.
mmo2011-002-006_a
1. To be pointed in the direction of rotation
3. Unscrew and remove the driven pulley expander from
the pulley.
4. Rotate the driven pulley several times to properly set the
belt between the sheaves.
5. If a new belt was installed, an adjustment will be required
for the proper belt height. Refer to DRIVE BELT HEIGHT AD-
JUSTMENT below.
6. Install belt guard, refer to CONTROLS, INSTRUMENTS AND
EQUIPMENT.
7. Close side panel, refer to CONTROLS, INSTRUMENTS AND
EQUIPMENT.
