Page 17 of 60
Installation DL2 Doppler Speed Log System
cu-m001-sa
O
pera
TOr
uniT
wiring
The operator unit has 2 connectors.
1 LAN connector for communication with Electronic unit.
2: W
AGO connector CN1 for 24V power
. Max 10W
, T
ypical 6W
.
Items supplied with CU-M001
1 x ZZN-01
120.
Connector Female w/ejectors 6x2 pole, black. (CN 1)
1 x ZZN-01
123. Strain relief plate, 6x2 pole, width 1
1 mm. (CN 1)
Note:
NMEA
and
CANBUS are
options not yet
implemented
16
