Skipper DL2 User Manual

2018-05-28
Page 37 of 60
Installation DL2 Doppler Speed Log System
For each of the outputs 1, 2 and LAN (UDPM) it is possible to activate a number of sentences.
Normally with On and Off. The resulting outputs are shown on the left on the screen.
The alarm output has 3 choices ALR, ALF and OFF. This because only one of these should be
selected at a time.
Output settings are password protected for changes.
The password for all units is ‘service’. The password will be remebered for 1 hour, or until reboot
of the system.
Window will show sen-
tences In/Out from
NMEA1, NMEA2 or UDP
In/Out select
Select NMEA1, NMEA2 or UDP
Output sentences settings for
NMEA1, NMEA2 and UDP
