Range selector key MEDIA26
– External audio sources, which are connected to the MEDIA-IN socket, can be oper-
ated via the radio ⇒ page 21.
It is possible to play back external audio sources via the loudspeakers of the radio in
the vehicle.
You can select another audio source on the radio at any time. As long as the external
audio source is not switched off, it remains always active in the background.
Please refer to the Owner's manual of the respective manufacturer for the operation of
the external audio source.
If a MEDIA-IN socket is additionally installed, the button is displayed
instead of the function key in the Audio menu. Please note that an audio source
connected to the AUX-IN socket can only be replayed, if there is currently no data
carrier connected to the MDI input.
Use the standard jack plug 3.5 mm for the AUX-IN socket. If the external audio source
does not have this jack plug, you must use an adapter.
Adjust the play function volume of the external audio source
The play function volume of the external audio source can be changed via the volume
control on the radio.
Depending on the connected audio source, the output volume on the external audio
source can be changed.
You can also change the input sensitivity of the external audio source, in order for the
play function volume of the external audio source to adapt to other audio sources or
to avoid distortions of the play function volume.
Adapter
A special adapter is required to connect audio sources via the input MDI.
We recommend that you purchase an adapter for connecting the USB devices, the
devices with Mini USB output or an iPod, at a Škoda Service Partner.
Conditions for proper connection
• Only USB devices with the specification 2.0 can be connected.
• The version of the file allocation table FAT (File Allocation Table) of the connected
device must be FAT16 (< 2 GB) or FAT32 (> 2 GB).
• In order to replay from a unit with a hard disk (HDD) which includes a large data
volume, it can lead to a time delay when reading in the overview of the music data.
• In order to replay from a unit, which includes a complicated folder structure, it can
lead to a time delay when reading in the overview of the music data.
• The folder structure in the connected unit must not exceed a depth of 8 levels. One
folder must not contain more than 1000°data.
• A USB extension cable or USB distributor (HUB) must not be used to connect the
unit.
WARNING
• On no account place an external audio source on the dash panel. You could
make sudden manoeuvres in the passenger compartment and injure the occu-
pants.
• On no account place an external audio source close to the airbags. You could
be thrown back in the passenger compartment by the airbags being deployed
and injure the occupants.
• You must not hold the external audio source in the hand or on the knees
while driving. You could make sudden manoeuvres in the passenger compart-
ment and injure the occupants.
• Always guide the connection cable of the external audio source in such a
way that is does not restrict you when driving.
Caution
The AUX-IN socket must only be used for audio sources!
Note
• The external audio source, which is connected via AUX-IN, can only be used if no
unit is connected via MDI at the same time.
• If an external audio source is connected via AUX-IN, which is equipped with an
adapter for external power supply, it can occur that the audio signal is interrupted. This
depends on the quality of the adapter which is used.
• The loudspeakers in the vehicle are matched to a power output of the radio of
30°W.
MEDIA-IN
AUX
