Range selector key NAV (Navigation)46
Waypoint nav. (Offroad Navigation)
Overview of the functions
Open waypoint mode
– Press on the function key in the main menu Navigation.
– Press on the function key in the pop-up window.
–The menu Waypoint navigation will open and the last active waypoint tour will be
indicated ⇒ fig. 19.
Leave waypoint mode
– In the waypoint mode, you can always change into the menu Waypoint navigation
by pressing the range selector key .
– There, press on the function key ⇒ fig. 19 and select the
in the pop-up window.
– Alternatively, you can terminate the waypoint mode by calling up the function key
in the menu Waypoint navigation.
– Once you have reached the destination of a waypoint tour, the waypoint mode will
close automatically and the “normal” main menu Navigation will open again.
When in the menu Waypoint navigation, the last active waypoint tour and its current
geo-position will be displayed. If no waypoint tour has been recorded or all of them
have been deleted, a corresponding message will be inserted. In this case the function
keys for starting, loading or processing a waypoint tour are not active.
If a waypoint tour is displayed, the waypoint tour will be started by pressing the func-
tion key .
The following menus and sub-menus are operated analog to the already described
menus of the navigation system and will no longer be described here in detail:
• Pressing on a displayed entry or the function key will always open the detailed
display.
• After pressing the function key , a pop-up window will open in which you can
correct the entry.
The function key
Pressing the function key will open a safety interrogation:
- switches back into the waypoint nav.
- terminates the waypoint nav. and opens the menu New dest. for
selection of an “Onroad destination” from the available navigation data.
The function key
Pressing the function key will open a pop-up window:
- opens a list of the stored waypoint tours. Press the corresponding
waypoint tour for selection.
- opens the waypoint tour memory. Stored waypoint tours
can be displayed, renamed or deleted.
The function key
Pressing the function key will open a pop-up window to display a new
waypoint tour or to process the displayed one.
- starts the display of a new waypoint tour after naming the
waypoint tour and selecting an acceptance mode. A displayed waypoint tour is auto-
matically stored and can be called up later via the function key by pressing
.
Fig. 19 Waypoint navigation
with active waypoint tour.
Extras
Waypoint nav.
NAV
Extras
Leave waypoint mode
New dest.
Start
0
H
New dest.
New dest.
Back
Onroad destination
Memory
Memory
Edit waypoint tour
Edit waypoint tour memory
Waypoint tour
Waypoint tour
Edit waypoint tour
Memory
Edit waypoint tour
s32k.a.book Page 46 Friday, September 18, 2009 1:54 PM
