Range selector key NAV (Navigation) 47
- opens a list with the waypoints of the tour currently displayed in
the menu Waypoint navigation. The waypoints in the list can be displayed, deleted,
moved or renamed in the map. Further waypoints can be added via the selection from
the map or the input of the GPS position. If you wish to edit a waypoint tour other than
the one displayed, you must first of all press the function key and then the
button .
Display a waypoint tour
– Press on the function key in the menu Waypoint navigation.
– Press on the function key in the pop-up window.
– If a tour is already being displayed in the menu Waypoint navigation you must
select by pressing in the following menu whether you wish to display the indicated
or a .
– Give a short and clear name to the waypoint tour. Confirm the displayed name by
pressing .
– Select an acceptance mode by pressing the respective key.
– Press the function key to allow the system to automatically set the
waypoints (recommended) during the display.
– Press the function key if you wish to set all waypoints yourself during the
display.
– After starting the display, the number of used and still available waypoints as well
as the set display mode will be indicated in the menu Waypoint navigation.
– Press the range selector key to change into the map display. Repeated
pressing of the range selector key will open and close the split-screen
⇒ fig. 20.
– Press on the range selector key to switch back into the main menu Waypoint
navigation.
– Press the function key to set the waypoints manu-
ally. When in the map display you can find this function key in the pop-up window
for the function key ⇒ fig. 20 ⇒ page 47, “Function key in the map
display”.
Function key in the map display
The waypoints used up to now for the tour and those still available are indicated in the
function key .
Pressing the function key ⇒ fig. 20 opens a pop-up window for controlling the
display.
- ends the recording; the last set waypoint becomes the endpoint of the
waypoint tour.
- switches on and off the function indicating that the waypoints
are set automatically via the sensors in the vehicle when changing the direction. A tick
in the check-box = indicates that the function is switched on.
- sets a manual waypoint at the current driving
position.
Driving a stored waypoint tour
Before you start driving a waypoint tour, you must be in the vicinity of the desired
starting point of this waypoint tour.
Edit waypoint tour
Memory
Edit waypoint tour
Fig. 20 Display in the map illus-
tration with a split-screen in the
compass display.
Waypoint tour
Edit waypoint tour
Extend existing tour New tour
OK
Automatic
Manual
MAP
MAP
NAV
Save current position as waypoint
Record
Record
Record
Record
Stop
= Automatic recording
Save current position as waypoint
s32k.a.book Page 47 Friday, September 18, 2009 1:54 PM
