Skyjack SJ3215 User Manual

216380ACA SJ3215, SJ3219, SJ3220, SJ3226, SJ4726, SJ4732, SJ4740
44
Section 4 – Inspections Before Operation
Function Tests
4.3-7 Do a test of the freewheeling
function
1. Make sure the path of travel is clear.
2. Put wheel chocks or blocks at the front of the
wheels and behind them to prevent MEWP
movement.
3. Turn the freewheeling valve knob
1
counterclockwise to a fully open position.
4. Release the brakes manually (refer to
Section 6.3).
5. Remove the wheel chocks or blocks.
6. Push or pull the MEWP.
▪
Result: The MEWP moves.
7. Put wheel chocks or blocks at the front of the
wheels and behind them to prevent MEWP
movement.
8. Turn the freewheeling valve knob clockwise to a
fully close position for operation.
9. Engage the brake (refer to Section 6.4).
4.3-8 Do a test of the emergency-stop
button on the platform
1. Make sure the main power disconnect switch is
in the on position.
2. Pull the emergency-stop button on the base
control console.
3. Turn the off/platform/base key switch to the
platform position.
WARNING
Fall hazard. Use the three points of contact
principle when you use the MEWP ladder to enter
or exit the platform. If you do not obey, there is a
risk of death or serious injury.
4. Use the MEWP ladder to enter the platform.
5. Close the gate.
6. Pull the emergency-stop
5
button on the
platform control console.
7. Move the lift/off/drive switch
4
to the drive
position.
8. Push the emergency-stop button.
9. Squeeze and hold the function-enable switch
3
.
10. Push the controller handle
2
to drive forward.
▪
Result: The drive function does not operate.
Platform control console
CUT OUT
TM
2
5
3
4
3 2
1
Free-wheeling valve
