Section 7 – Specifications
Floor loading pressure
7.6 Floor loading pressure
Model
Weights Pressures
MEWP weight
Max weight per
wheel
LCP** OFL**
kg lb kg lb kPa psi kPa psf
SJ3215
Min* 1148 2531 290 640 872 126.5 7.9 164
Max* 1420 3131 490 1080 1106 160.4 9.7 202
SJ3219
Min* 1476 3255 370 816 961 139.4 10.1 210.9
Max* 1703 3755 608 1340 1134 164.5 11.7 244.4
SJ3220
Min* 1776 3917 445 981 982 142 9.6 201
Max* 2184 4817 853 1880 1202 174 11.9 248
SJ3226
Min* 1900 4190 475 1047 1070 155 10.3 215
Max* 2127 4690 794 1750 1193 173 11.5 241
SJ4726
Min* 2511 5537 628 1384 1479 215 9.5 198
Max* 2965 6537 1161 2560 1569 228 14.2 234
SJ4732
Min* 2492 5496 623 1374 1478 214 9.4 197
Max* 2809 6196 1066 2350 1559 226 10.6 222
SJ4740
Min* 2934 6467 735 1620 1520 220 10.0 208
Max* 3284 7237 1270 2800 1585 230 11.2 233
* Min: Minimum MEWP weight (Unloaded platform, no options/attachments)
Max: Maximum MEWP weight (Platform loaded to capacity with options/attachments)
Wheel is the weight that can be experienced on one wheel.
Note: This is more than 25% of the machine weight due to possible weight distribution over the machine and platform.
** LCP: Local Concentrated Pressure is a measure of how hard the MEWP presses on the area in direct contact with the floor/tire.
OFL: Overall Floor Load (Pressure) is a measure of the average load the MEWP imparts on the whole surface directly underneath the
chassis. This has been calculated by dividing the MEWP weight by the overall floor area occupied by the MEWP (on wheels).
Note: The floor covering (e.g., tile, carpet, etc.) or the structure (e.g., beams) of the operating surface must
be able to withstand more than the values indicated above.
Note: The LCP or OFL that an individual surface can withstand varies from structure to structure and is
generally determined by the engineer or architect for that particular structure.
