Specifications Section 7 – Specifications
7.3 Specifications
Models SJ3215 SJ3219 SJ3220 SJ3226 SJ4726 SJ4732 SJ4740
Weight *
1148 kg
2531 lb
1476 kg
3255 lb
1776 kg
3917 lb
1900 kg
4190 lb
2511 kg
5537 lb
2484 kg
5476 lb
2934 kg
6467 lb
Overall width
0.82 m
32.28 in
0.84 m
33 in
1.20 m
47.29 in
Overall length
1.80 m
70.87 in
2.33 m
91.61 in
2.40 m
94.66 in
Platform Size (Inside)
0.65 m x 1.54 m
25.59 in x 60.63 in
0.7 m x 2.10 m
27.56 in x 82.75 in
1.06 m x 2.10 m
41.85 in x 82.75 in
1.06 m x 2.19 m
41.85 in x 86.21 in
Height
Working Height
6.27 m
21 ft 2 in
7.48 m
24 ft 6 in
7.78 m
25 ft 6.1 in
9.62 m
31 ft 7 in
9.65 m
31 ft 8 in
11.48 m
37 ft 8 in
13.69 m
44 ft 11 in
Platform Elevated Height
4.44 m
14 ft 7 in
5.65 m
18 ft 6 in
5.95 m
19 ft 6.1 in
7.79 m
25 ft 7 in
7.71 m
25 ft 7 in
9.65 m
31 ft 8 in
11.86 m
38 ft 11 in
Stowed Height (Railings Down)
1.67 m
65.75 in
1.79 m
70.47 in
1.75 m
68.96 in
1.93 m
76.08 in
1.90 m
74.84 in
1.99 m
78.45 in
2.03 m
79.76 in
Stowed Height (Railings Up)
2.03 m
79.92 in
2.14 m
84.25 in
2.10 m
82.85 in
2.29 m
89.95 in
2.29 m
89.95 in
2.38 m
93.58 in
2.53 m
99.53 in
Drive Height FULL
Standard Operating Times
Lift Time (No Load) 15 s 15 s 24 s 45 s 46 s 47 s 61 s
Lower Time (No Load) 22 s 32 s 32 s 49 s 43 s 36 s 48 s
Lift Time (Rated Load) 17 s 17 s 28 s 47 s 52 s 50 s 68 s
Lower Time (Rated Load) 16 s 24 s 24 s 41 s 32 s 30 s 41 s
Chassis
Normal Drive Speed
3.38 km/h
2.1 mph
3.88 km/h
2.4 mph
3.24 km/h
2.0 mph
3.0 km/h
1.9 mph
Elevated Drive Speed
1.13 km/h
0.7 mph
0.97 km/h
0.6 mph
0.97 km/h
0.6 mph
0.8 km/h
0.5 mph
Gradeability (Ramp Angle) 25%
Tires (Solid Rubber) 12 x 4 x 8 16 x 5 x 12
Hydraulic Oil
Type ATF Dexron III
Tank Capacity (Liters) 11.3 L (3 gal) 30.3 L (8 gal) 28 L (7.5 gal)
Sound Pressure Level at Platform Level
Does not exceed: 70 db(A) 76 db(A)
1336AA* Weight with standard 0.9 m extension platform. Refer to serial nameplate for specific applications.
