SJ46 AJ, SJ51 AJ, SJ63 AJ 213210AAAA
25
Control functions Section 3 – Familiarization
11
Glow plug (diesel engine): This light illuminates
until the glow plugs complete their timed-cycle.
When the light goes off, you can start the engine.
12
Engine: This light shows a failure in the engine
control system.
13
Base/off/platform key: With this three-way
switch, you can:
▪
Turn off the power to the MEWP controls.
▪
Energize the base controls.
▪
Energize the platform controls.
14
Start/function enable/emergency-power: In the
start position, this switch starts the engine. In the
function enable position, this switch lets the base
control functions operate. The engine speed
increases when the function enable position is
selected. In the emergency-power unit position,
with the engine off, this switch lets the base
control functions operate with the emergency-
power unit.
WARNING
Tip-over hazard. Do not operate the boom
functions if the platform capacity is more than the
rated platform capacity. If you do not obey, there is
a risk of death or serious injury.
2
1
12
13
7
14 4 8 5
9
6
11
10
3
