3.5-3 Glazier
The glazier tray attaches to the kickplate of the
platform. Refer to the glazier operation manual for the
correct operation and maintenance.
3
2
1
7
1
Strap: The strap holds the panel in position.
7
2
Foam Support: The foam support gives
protection to the panel.
7
3
Glazier Tray: The tray holds the panel.
3.5-4 Pipe Rack
The pipe rack attaches to the top platform railings.
Refer to the pipe rack operation manual for the correct
operation and maintenance.
1
2
7
1
Cradle: The cradles hold the pipes.
7
2
Strap: The straps secure the pipes to the cradle.
