Section 7 – Technical Diagrams and Specications Maximum platform capacities (evenly distributed)
7.7 Maximum platform capacities (evenly distributed)
7.8 Floor loading pressure
Model
Weights Pressures
Gross MEWP Weight Max Weight per Wheel* LCP** OFL**
kg kg kPa kPa
SJ46 AJ (standard
con guration)
6727
3315 856 10.1
SJ51 AJ (standard
con guration)
7527
3640 940
11.0
SJ63 AJ (standard
con guration)
10 427 5080 1195 12.4
1921AA
Standard con guration (SJ46 AJ, SJ51 AJ): 4WD + oscillating axles + 30.5 cm x 41.9 cm foam tires
Standard con guration (SJ63 AJ): 4WD + oscillating axles + 35.5 cm x 44.5 cm foam tires
Gross MEWP weight: weight + platform capacity
*
Wheel is the weight that can be experienced on one wheel.
Note: This is more than 25% of the machine weight due to possible weight distribution over the machine and platform.
**
LCP: Local Concentrated Pressure is a measure of how hard the MEWP presses on the area in direct contact with the  oor/tire.
OFL: Overall Floor Load (Pressure) is a measure of the average load the MEWP imparts on the whole surface directly underneath the
chassis. This has been calculated by dividing the MEWP weight by the overall  oor area occupied by the MEWP (on wheels).
Note:
The floor covering (e.g., tile, carpet, etc.) or the structure (e.g., beams) of the operating surface must be able to withstand more than
the values indicated above.
NOTE
The LCP or OFL that an individual surface can withstand varies from structure to structure and is
generally determined by the engineer or architect for that particular structure.
SJ46 AJ SJ51 AJ SJ63 AJ
Total Platform Capacity
227 kg
2 Persons
Wind Rating
12.5 m/s
Manual Side Force
400 N
Tilt Cutout Setting (side-to-side x front-to-back)
5 degrees x 5 degrees
1919AA
