213210AAAA SJ46 AJ, SJ51 AJ, SJ63 AJ
54
Section 4 – Inspections Before Operation Function tests
14. Press the sensor bar for less than 1 second and
then release it.
▪
Result: The function will stop while the bar is
pressed, and the function will continue when
the bar is released. The audible/visual alarm
goes on while the bar is pressed and goes off
after it is released. The reset button illuminates
when the bar is pressed and goes off when the
bar is released.
15. Press the sensor bar for more than 1 second
and then release it.
▪
Result: The function will stop, and the audible/
visual alarm goes on immediately and stays
on after the bar is released. The engine stops
after 1 second. The reset button illuminates.
16. While the audible/visual alarm
6
is on, make
sure the LED strobe light is also on.
4.3-11 Do a test of the engine start/on/off
switch
1. Make sure the engine is on.
2. Select the off position from the engine start/on/
off
7
switch.
▪
Result: The engine stops and the platform
control console is disabled.
3. Select the on position from the engine start/on/
off switch.
▪
Result: The platform control console is
enabled.
4. Select the start position from the engine start/
on/off switch to start the engine.
TM
1
2
+
+
A
6
7
