Skyjack SJ46 AJ User Manual

SJ46 AJ, SJ51 AJ, SJ63 AJ 213210AAAA
65
Move the riser up and down with the platform control console Section 5 – Operation
5.14 Move the riser up and
down with the platform
control console
1. Press and hold the footswitch.
2. Move the riser up/down switch to the up or
down position. Release the switch to stop.
5.15 Extend or retract the boom
with the platform control
console
1. Press and hold the footswitch.
2. Move the boom extend/retract switch to the
extend or retract position. Release the switch to
stop.
5.16 Make the platform level
with the platform control
console
1. Press and hold the footswitch.
2. Move the platform-leveling override switch to
the up or down position. Release the switch to
stop.
5.17 Rotate the platform with
the platform control
console
1. Press and hold the footswitch.
2. Move the platform rotation switch to the left or
right. Release the switch to stop.
5.18 Raise or lower the main
boom with the platform
control console
1. Press and hold the footswitch.
2. Move and hold the boom/turret controller
handle forward or rearward to raise or lower the
main boom.
3. Move the boom/turret controller handle to the
neutral position to stop. Release the footswitch.
5.19 Operate the horn
1. Push the horn button to make a sound. Release
the button to stop.
5.20 Rotate the turret with the
platform control console
WARNING
Before you rotate the turret, make sure there
are no personnel or obstructions in the path of
rotation, which includes blind spots. If you do not
obey, there is a risk of death or serious injury.
1. Press and hold the footswitch.
2. Move and hold the boom/turret controller
handle to the left or right to rotate the turret
clockwise or counterclockwise.
3. Move the boom/turret controller handle to the
neutral position to stop. Release the footswitch.
NOTE
The turret can rotate 360 degrees continuously.
