Section 7 – Technical Diagrams and Specications Specifications
7.4 Specications
Model SJ46 AJ SJ51 AJ SJ63 AJ
Platform Size
Total Platform Length (Outside)
1.83 m 1.83 m/ 2.44 m
Total Platform Depth (Outside)
0.76 m 0.91 m
Height
Working
15.4 m 16.8 m 21.38 m
Platform Elevated
14.2 m 15.6 m 19.38 m
Drive (Maximum)
Driveable at all heights
Stowed
2.06 m 2.54 m
Length
Overall with Platform
6.5 m 7.25 m 9.14 m
Width
Outside Standard Tires
2.2 m 2.44 m
Weight
With Foam- lled Tires
6400 kg 7300 kg
9934 kg
Platform Rotation
180 degrees 175 degrees
Horizontal Reach
7.68 m 9.16 m 12.19 m
Horizontal reach at maximum height 2.58 m 2.96 m 4.80 m
Wheelbase
2.03 m 2.44 m
Turret Rotation
360 degrees
Turret Tailswing
-12.7 cm 0 m
Maximum Gradeability
45%
Ground Clearance Under Axle
40.6 cm 33 cm
Turning Radius
Inside
4WD
1.50 m 2.21 m
Outside
4.34 m 5.31 m
System Voltage
12 V DC
Battery
Type
Lead/Acid
Cold Cranking Amperes
800 A 925 A
Operating Times
Main Boom Up
23 - 29 seconds 26 - 34 seconds
Main Boom Down
23 - 29 seconds 26 - 34 seconds
Riser Up
23 - 29 seconds 23 - 31 seconds
Riser Down
23 - 29 seconds 23 - 31 seconds
Fly Boom Extend 8 - 14 seconds 12 - 18 seconds
26 - 34 seconds
Fly Boom Retract
16 - 22 seconds
23 - 29 seconds
30 - 38 seconds
Jib Up
34 - 44 seconds 17 - 23 seconds
Jib Down
18 - 28 seconds 15 - 21 seconds
Turret Rotate
90 - 110 seconds 109 - 135 seconds
Platform Rotate
15 - 25 seconds 6 - 11 seconds
Driving Speeds
Travel Speed (Lowered Travel
Position)
7.7 km/h 7.3 km/h
Travel Speed (Elevated Travel
Position)
≤ 0.8 km/h
1914AA
