Page 3
BASIC RECOMMENDED TOOLS:
1/8". 1/4" STRAIGHT BLADE SCREWDRIVERS
#2 PHILLIPS SCREWDRIVER
HYDRAULIC PRESSURE GAUGE SKYTRON P.N. 6-050-02
METRIC ALLEN
WRENCHES 1.5mm-8mm
ADJUSTABLE CRESCENT WRENCH
DIGITAL VOLTMETER, TRUE RMS
METRIC OPEN END WRENCHES 7mm-18mm
LEVEL (CARPENTERS)
GREASE GUN
BEARING GREASE P.N. D6-010-89-1
BASIC RECOMMENDED MAINTENANCE PROCEDURES
The basic items notes below should be inspected at a minimal interval period of 6 months (dependant on
usage). For optimal usage, safety and longevity of the product, have it serviced only by an authorized
Skytron representative with authentic Skytron replacement parts.
• Check Power Cord (if applicable)
• Check Pendant Control (if applicable)
• Check Oil Level in Reservoir
• Check For Hydraulic Leaks
• Check Pressure Relief Valve Setting
• Check All Table Functions
• Check Side Rails and Gravity Stops
• Check Velcro
• Check Lateral Tilt Housing Bolts
• Lubricate Elevation Slider Assembly with Mobilux EP (Extreme Pressure) Grease P/N D6-010-89-1
• Tighten X-Ray Top Stand-Offs, Use Blue Loc-Tite
• Lubricate Casters
• Check brake pads for wear and inspect brake cylinders for proper operation.
• Inspect the Trendelenburg Cylinder & Ball Joint Retainer Nut
Only facility-authorized Skytron trained, maintenance personnel should troubleshoot the
Skytron 3501B EZ SLIDE Surgical Table. Trouble shooting by unauthorized personnel
could result n personal injury or equipment damage.
How to contact us:
SKYTRON
5000 36th St. SE, Grand Rapids, MI 49512
PH: 1-800-759-8766 (SKY-TRON)
FAX: 616-957-5053
