SkyWave IDP-680 - Figure 3 IDP-680 with Side Connector; Figure 4 IDP-680 with Bottom Connector; Table 1 IDP 600 Series Models

IDP 600 Terminal Series - Hardware Guide
© SkyWave Proprietary 3 T200, Version 02
Table 1 IDP 600 Series Models
Model
Elevation Angle
Connector
GPS
(optional)
IDP-680
20° - 90°
10-pin
side or bottom
Yes
IDP-690
-15° - 90°
10-pin
side or bottom
Yes
Part numbers are specified in Table 9.
All terminals are available in two configurations: bottom connector or side connector (see
figures below).
Figure 3 IDP-680 with Side Connector
Figure 4 IDP-680 with Bottom Connector
