SkyWave IDP-680 - Led; Non-Volatile Storage; Figure 19 IDP-690 Side View Enclosure Dimensions (MM)

IDP 600 Terminal Series - Hardware Guide
T200, Version 02 20 © SkyWave Proprietary
Figure 19 IDP-690 Side View Enclosure Dimensions (mm)
IDP-680
Parameter
Value
Mass
460 g
Enclosure Material
Xenoy® 5220U Resin
5
IDP-690
Parameter
Value
Mass
460 g
Enclosure Material
Xenoy® 5220U Resin
5
3.8 LED
The terminal has an integral LED to indicate that the terminal has successfully powered
up (Section 4.8).
The visual indicator (LED) does not indicate satellite status. Its only purpose is to
confirm terminal start-up.
Parameter
Value
Color
Red
3.9 Non-Volatile Storage
The IDP 600 series has non-volatile flash memory that is shared by the terminal firmware
and user services.
Parameter
Value
Non-volatile On-board Flash Storage
4 MB
Write-Erase Cycles (per operating life)
100 000
5
For additional details, see http://www.ides.com/PWeb/obds.aspx?E=15025
