IDP 600 Terminal Series - Hardware Guide
T200, Version 02 18 © SkyWave Proprietary
3.5.2 IDP-680 Antenna
Parameter
Value
Maximum EIRP
7 dBW
Elevation Angle
20 degrees elevation
3.5.3 IDP-690 Low Elevation Antenna
Parameter
Value
Maximum EIRP
5.0 dBW
Elevation Angle
-15 degrees elevation
3.6 GPS
Standard GPS
Parameter
Value
Receive Type
GPS C/A Code
Frequency
L1 (1575.42 MHz)
Mean Time to First Fix
Cold Start
36 s
Warm Start
8 s
Sensitivity
Tracking
-146 dBm
Acquisition
-136 dBm
Accuracy
Horizontal Position (CEP)
4 m
Horizontal Speed (CEP)
0.02 m/s
Heading (at 100 km/hr speed; 50%)
0.1°
3.7 Physical Details
The terminal’s mechanical enclosure is a rugged, impact, and chemical resistant plastic
material. All dimensions are shown in millimeters (mm).
