APPENDIX C IDP 600 Series Mating Cable
This cable (ST301005-001) connects the IDP terminal to external I/O lines and serial
ports. There are a total of ten pins on this blunt cut cable; two connect the terminal to an
RS-232 console serial port or an RS-485, four wires to connect to external I/O lines, and
one each for ground and voltage. The cable has an over-molded connector.
Figure 42 IDP 600 Series Mating Cable
Specifications
