3. Contents of the Carton
Inside the carton will be the following:
DESCRIPTION
SLA PART NUMBER
4000 Series Tester
4000 Hipot, Ground Bond, IR Tester
High Voltage Probe
102-050-913
High Voltage Cable
102-055-913
High Current Return Lead
99-10008-01
High Current Output Lead
99-10009-01
Fuse
99-10106-01, 6.3 Amp, slow blow, 250VAC
Interlock Connector
99-10040-01
Line Cord*
125-013-001 Standard
*The Line Cord listed is American. Other combinations of the Line Cord are available upon request.
ONLY ACCESSORIES WHICH MEET THE MANUFACTURER’S SPECIFICATION SHALL BE
USED.
4. Preparation for Use
Power Requirements and Line Voltage Selection
This tester requires a power source of either 115 volts AC ± 10%, 47-63 Hz single
phase or 230 volts AC ±10%, 47-63 Hz single phase. Please check the rear panel to
be sure the proper switch setting is selected for your line voltage requirements
before turning your tester on (model 4320 only). In addition, please be sure the correct fuse is selected
and installed while the tester is in the off position.
Do not switch the line voltage selector switch located on the rear panel while the tester is on or operating
(model 4320 only). This may cause internal damage and represents a safety risk to the operator.
NOTE
For operation at 115 Volts AC and 230 Volts AC use a 6.3 A slow blow fuse (model 4320).
For operation at 115 Volts AC and 230 Volts AC use a 15 A slow blow fuse (model 4520).
WARNING
CAUTION
