Appendix E - Replacement Parts List - Model 4320/4520
Rev: D
PART
NUMBER
QTY.
REFERENCE
DESIGNATOR
DESCRIPTION
99-10320-01
1
CON4320
Main Control Board 4320
99-10639-01¹
1
CON4320
Main Control Board 4520
99-10321-01
1
AMP4320
Amplifier Board 4320
99-10637-01¹
1
AMP3780
Amplifier Board 4520
99-10322-01
1
HV4320A
HV Control Board 4320
99-10638-01¹
1
HV4320H
HV Control Board 4520
99-10323-01
1
RY4320
HV AC/DC Switch Board 4320
99-10641-01¹
RY4320
HV AC/DC Switch Board 4520
99-10324-01
1
CKB-06
Keypad Board
99-10572-01
1
RS232-M1
RS232 Interface Board
99-10573-01
1
-
RS232 Cable
99-10325-01²
1
PWR3670
Input Voltage Select Board 4320
99-10326-01
1
REM4320
Remote Board
99-10640-01¹
1
OPT4520
Output Switch Board 4520
99-10016-01
1
-
Earth Connector
99-10018-01
1
-
High Voltage Connector
99-10673-01
1
-
Return Terminal
99-10674-01
1
-
Current Terminal
175-946-013
1
-
Feet Kit w/o Rubber Inserts
175-974-002
4
-
Rubber Insert
99-10106-01²
1
-
Fuse 6.3A, 250V, Slow Blow, 5x20mm
99-10656-01¹
1
-
Fuse 15A, 250V Slow Blow
99-10297-01²
1
-
Fuse Holder 20mm
99-10650-01¹
1
-
Fuse Holder 30mm
99-10355-01
1
-
LCD Display 16 x 2 Characters
99-10312-01²
1
-
Power Switch 2P 15A
330-118-001¹
1
-
Power Switch 2P 250V 10A
330-113-001
1
-
Test Switch, Green
330-113-002
1
-
Reset Switch, Red
99-10333-01²
1
T1
Input Transformer
99-10334-01
1
T2
Output High Voltage Transformer
99-10653-01¹
1
T2
Output 500VA HV Transformer
99-10654-01¹
1
T3
Ground Bond Transformer
125-013-001
1
-
Input Power Cable 10A/6Ft.
