Slaughter 4320 - Page 57

51
PART
NUMBER
QTY.
REFERENCE
DESIGNATOR
DESCRIPTION
102-050-913
1
-
High Voltage Probe
102-055-913
1
-
High Voltage Output cable
99-10008-01
1
-
Return cable
99-10009-01
1
-
Current cable
99-10028-01
11
Q…
Power Transistors on AMP4320
99-10029-01
1
RY1
Relay Gunther 3392-1290-246 on RY4320
99-10033-01
1
RY2
Relay Gunther 3390-1290-246 on RY4320
99-10303-01
1
IC2
Microcontroller 8 Bit W78E516B
99-10304-01
1
IC24
Microcontroller 8 Bit SM8951A
99-10030-01
1
IC50
12 Bit D/A Converter 7541
99-10032-01
1
IC20
8 Bit D/A Converter DAC 0800
99-10671-01
1
Test/Pass
Replacement Bulb
99-10672-01
1
Reset/Fail
Replacement Bulb
¹ 4520 Only
² 4320 Only
