Model 4520 Functional Specifications
Unless otherwise stated, accuracy's are relative to a laboratory standard measurement.
INPUT
Voltage
115 / 230V Auto Range,  15  variation
Frequency
50 / 60 Hz  5%
Fuse
15 A slow blow 250V AC
HIPOT TEST MODE
Output Rating
5 kV @ 100 mA AC
6 kV @ 10 mA DC
Voltage Setting
Range: 0.00 – 5.00 kV AC
0.00 – 6.00 kV DC
Resolution: 0.01 kV
Accuracy:  (2  of setting + 5 V)
Voltage Display
Range: 0.00 – 5.00 kV AC
0.00 – 6.00 kV DC
Resolution: 0.01 kV
Accuracy:  (2  of reading + 10 V)
Current Display
Range: 0.00 – 99.99 mA AC
0.00 – 10.00 mA DC
Resolution: 0.01 mA
Accuracy:  (2  of reading + 6 counts)
HI and LO-Limit
Range: 0.00 – 99.99 mA AC
Resolution: 0.01 mA
Accuracy:  (2  of setting + 6 counts)
Range: 0.00 – 10.00 mA DC
Resolution: 0.01 mA
Accuracy:  (2  of setting + 6 counts)
Failure Detector
Audible and Visual
Discharge Time
 200 ms
Maximum Capacitive
Load in DC Mode
1 uF  1 kV
0.75 uF  2 kV
0.5 uF  3 kV
0.08 uF  4 kV
0.04 uF  5 kV
0.01 uF  6 kV
AC Output Waveform
Sine Wave, Crest Factor = 1.3 – 1.5
AC Output Frequency
Range: 60 or 50 Hz, User Selectable
Accuracy:  0.1 
Output Regulation
 (1  of setting + 5 V) from no load to full load
Dwell Timer
Range: 0, 0.2 – 999.9 sec (0 = Continuous)
Resolution: 0.1 sec
Accuracy:  (0.1  + 0.05 sec)
