4 TECHNICAL DATA
Table 4.7 – Continued from previous page
Pin Signal Function
10 DOUT-1 Fast Digital Output 1
29 DOUT-2 Fast Digital Output 2
11 DOUT-3 Fast Digital Output 3
28 GNDiso Corresponding GNDiso for DOUT-1/-2/-3
12 AIN-6 Fast Analog Input 6
30 GNDiso Corresponding GNDiso for AIN-6
13 AIN-5 Fast Analog Input 5
31 GNDiso Corresponding GNDiso for AIN-5
14 AIN-4 Fast Analog Input 4
32 GNDiso Corresponding GNDiso for AIN-4
15 AIN-3 Fast Analog Input 3
33 GNDiso Corresponding GNDiso for AIN-3
16 AIN-2 Fast Analog Input 2
34 GNDiso Corresponding GNDiso for AIN-2
17 AIN-1 Fast Analog Input 1
35 GNDiso Corresponding GNDiso for AIN-1
18 AOUT-2 General Purpose Analog Output 2
36 GNDiso Corresponding GNDiso for AOUT-2
19 AOUT-1 General Purpose Analog Output 1
37 GNDiso Corresponding GNDiso for AOUT-1
1 d.n.c DO NOT CONNECT, Internally Used
2-5 NC Not Connected
Shielding GND Ground
27
