2 PRODUCT OVERVIEW
Table 2.6 – Continued from previous page
Name Type Connectors Function
AIN-n 6 Fast Analog Inputs D-SUB37 General Purpose Analog Input, Control
Loop Feedback
HSDR 1 USB Interface USB type B High Speed Data Reader
2.2 MCS2 Sensor Module
For positioners with integrated sensors a sensor module is required to digitize the sensor data.
The sensor module type depends on the sensor type, the driver type and the connector to the
positioner. The configuration of the sensor module is defined by the product code below. In table
2.7 you will find all available configuration options.
MCS2
S 0001
Housing Type
Constellation Code
Table 2.7 – Product Codes
Product Code Description Connectors
MCS2-S-0001 Sensor Module for up to 3 positioners 3x D-SUB-15 female
2.3 MCS2 Accessories
In addition to the modules above, some optional accessories may be required for specific config-
urations. In table 2.8 you will find a list of available accessories.
Table 2.8 – Product Codes
Product Code Description Connectors
MCS2-A-PS-CABLE-1.5M-1.5M Adapter cable for MCS2 and PicoScale 3x D-SUB-15 female
16
MCS2 User Manual
