SmarAct MCS2 - Auxiliary Fast Analog Inputs

4 TECHNICAL DATA
Table 4.12 – Continued from previous page
Parameter Condition MIN TYP MAX Unit
V
offset
±4 mV
V
noise
860 µV
pp
t
settling
290 µs
Slew rate measured btw. 10 to 90 % of a full-scale transition 0.163 V/µs
DC crosstalk channel to channel 60 µV
4.4.5 Auxiliary Fast Analog Inputs
The fast analog inputs feature an ADC with 16bit resolution and a build-in 2nd-order low pass
filter. All inputs are galvanically isolated to the internal ground of the controller. The correspond-
ing GND signals of the specific inputs should be used to archive the best performance. The input
range of the analog inputs is configurable for unipolar as well as bipolar operation. Note that this
setting is global for all analog inputs. The total number of six analog inputs are mapped in groups
of two to the channels of the corresponding driver module.
Table 4.13 – Fast Analog Inputs Specification
Parameter Condition MIN TYP MAX Unit
Common
V
iso
60 V
R
iso
10 MΩ
Fast Analog Inputs
V
ovp
-11 11 V
R
i
500 kΩ
F
co
-3dB 15 kHz
F
sample
per channel 50 kHz
INL ±1 2 LSB
DNL ±0.5 1.5 LSB
SINAD 91.5 dB
E
gain
0.1 % FSR
E
offset
±0.5 mV
V
i
input range=5.12V 0 5.12 V
V
i
input range=10.24V 0 10.24 V
V
i
input range=±2.56V -2.56 2.56 V
Continued on next page
32
MCS2 User Manual
