4 TECHNICAL DATA
4.4.6 Abbreviations
• V
iso
: allowed voltage difference from isolated ground to internal ground
• R
iso
: isolation resistance from isolated ground to internal ground
• V
cc
: configured common supply voltage
• V
oh
: minimal output value if output is set high
• V
ol
: maximal output value if output is set low
• V
o
: output voltage range
• I
o
: allowed output current
• I
oh
: output current during high state (source current)
• I
ol
: output current during low state (sink current)
• V
i
: allowed input voltage
• V
ovp
: overvoltage protection voltage
• V
ih
: input voltage that is interpreted as high level
• V
il
: input voltage that is interpreted as low level
• R
i
: input impedance value
• R
o
: output impedance value
• F
co
: input filter cut-off frequency
• INL: integral nonlinearity
• DNL: differential nonlinearity
• SINAD: signal-to-noise ratio
• E
gain
: gain error
• E
offset
: offset error in % full-scale-range (FSR)
• V
offset
: offset error
• V
noise
: DAC output noise
• t
settling
: output voltage settling time (transition time between 1/4 scale and 3/4 scale, includ-
ing settling to ±0.024 % within FSR)
