Vehicle with steel wheels and hub caps:
X
Using both hands, grasp two hub cap open-
ings and remove the hub cap.
Vehicle with steel wheels and wheel hub cov-
ers:
X
Remove the wheel hub cover.
X
Using wheel wrench : loosen the wheel
bolts by about one turn. Do not unscrew the
wheel bolts completely.
The vehicle may only be raised at the desig-
nated jacking
points. The jacking points are
located just behind the front wheel arches and
just in front of the rear wheel arches.
X
Position jack ; under the triangular
indentations for jacking point :.
X
Set the foot of the jack up vertically with
respect to
the jacking point on the vehicle.
X
Raise the vehicle with the jack until the
tyre is at most 3 cm off the ground.
X
Unscrew and remove the wheel bolts.
X
Remove the wheel.
Changing a wheel
133
>> Maintenance and care.
