APC615 Pump Unit Controller User Manual
APC615 Pump Unit Controller Version 1.0 2017-10-20 Page 24 of 54
No.
Items
Parameter
Default
Description
1
Curve Type
(0-15)
4
SGD. See table 12.
2
Open Circuit Action
(0-2)
0
0: Warning; 1: Shutdown; 2: No action
3
Display Unit
(0-1)
0
0: ℃; 1: ℉
4
Fuel Tank Capacity
(0-10000)L
1000
It is can be set if fuel unit select “L”.
5
Low Level
Shutdown
(0-1000)%
0
Shutdown when fuel level of external
connected sensor is lower than this value. The
delay value can be set.
6
Low Level Warning
(0-1000)%
10
Warning when fuel level of external connected
sensor is lower than this value. It is detecting
all the time. The delay value and return value
can be set.
7
Fuel Pump Output
(0-1000)%
10
Fuel pump outputs when fuel level of external
connected sensor is lower than this value. The
delay value and return value can be set.
8
Custom Curve
Users should set the corresponding curve
when select resistor curve type or current
curve type.
Engine Oil Pressure Sensor
1
Curve Type
(0-15)
9
SGD. See table 12.
2
Open Action
(0-2)
0
0: Warning; 1: Shutdown; 2: No action.
3
Display Unit
(0-2)
0
0: kPa; 1: bar; 2: psi;
4
Low Oil Pressure
Shutdown
(0-1000)kPa
103
Shutdown when oil pressure of external
connected sensor is lower than this value.
Detecting only after safety delay is over. The
delay value can be set.
5
Low Oil Pressure
Warning
(0-1000)kPa
124
Warn oil pressure of external connected
sensor is lower than this value. Detecting only
after safety delay is over. The delay value and
return value can be set.
6
Custom Curve
Users should set the corresponding curve
when select resistor curve type or current
curve type.
Outlet Pressure Sensor
1
Curve Type
(0-15)
2
Custom 4-20mA curve. See table 12.
2
Open Action
(0-2)
0
0: Warning; 1: Shutdown; 2: No action.
3
Display Unit
(0-3)
0
0: kPa; 1: bar; 2: psi; 3: MPa;
4
High Shutdown
(0-9000)%
120
Shutdown when value of external connected
sensor is higher than this value. Alarm enabled
or not and delay value can be set.
5
Low Shutdown
(0-9000)%
10
Shutdown when value of external connected
sensor is lower than this value. Alarm enabled
or not and delay value can be set.
6
High Warning
(0-9000)%
110
Warning when value of external connected
sensor is higher than this value. Alarm enabled
