Smartgen APC615 User Manual

APC615 Pump Unit Controller User Manual
APC615 Pump Unit Controller Version 1.0 2017-10-20 Page 25 of 54
No.
Items
Parameter
Default
Description
or not, return value, and delay value can be
set.
7
Low Warning
(0-9000)%
20
Warning when value of external connected
sensor is lower than this value. Alarm enabled
or not, return value, and delay value can be
set.
8
Custom Curve
Users should set the corresponding curve
when select resistor curve type or current
curve type.
9
Rated Outlet
Pressure
(0-9000)kPa
1000
Configure the rated working pressure of outlet.
10
Static Pressure
(-9000-9000)kPa
0
Configure the static pressure of outlet.
11
Flow Enable
(0-1)
0
0: Disable；1: Enable
12
Flow Unit
(0-1)
0
0: m³/h; 1:L/s
13
Rated Flow
(0-10000)m³/h
1000
Rated working flow of pump unit.
14
Over Flow Warning
(0-1000)%
110
While unit is running, if flow exceeds the
setting point, warning alarms will be initiated.
Alarm enabled or not, return value, and delay
value can be set.
15
Over Flow
Shutdown
(0-1000)%
120
While unit is running, if flow exceeds the
setting point, shutdown alarms will be initiated.
Alarm enabled or not, return value, and delay
value can be set.
16
Flow Curve
Different discharge pressures correspond to
different flow values.
Flexible Sensor 1~2
1
Flexible Sensor
Setting
(0-7)
0
0: Not used ； 1: Temperature sensor; 2:
Pressure Sensor; 3: Fuel level Sensor; 4: Flow
sensor; 5: Pipe pressure sensor; 6: Inlet
pressure sensor; 7: Water level sensor of tank.
2
Curve Type
It is depends on sensor type.
3
Open Action
(0-2)
0
0: Warning; 1: Shutdown; 2: No action.
4
Display Unit
(0-1)
0
0: ℃; 1: ℉
Note: different sense displays different unit.
5
High Shutdown
(0-9000)
0
Shutdown when external sensor value is
higher than this value. Alarm enabled or not
and delay value can be set.
6
Low Shutdown
(0-9000)
0
Shutdown when external sensor value is lower
than this value. Alarm enabled or not and delay
value can be set.
7
High Warning
(0-9000)
0
Warn when external sensor value is higher
than this value. Alarm enabled or not, return
value, and delay value can be set.
8
Low Warning
(0-9000)
0
Warn when external sensor value is lower than
