this value. Alarm enabled or not, return value,
and delay value can be set.
9
Custom Curve
Users should set the corresponding curve
when select resistor curve type or current
curve type.
Digital Input Ports
Digital Input Port 1
1
Contents Setting
(0-53)
28
Remote start. See table 11.
2
Active Type
(0-1)
0
0: Active: Close 1: Active: Open
Digital Input Port 2
1
Contents Setting
(0-53)
26
High temperature shutdown. See table 11.
2
Active Type
(0-1)
0
0: Active: Close 1: Active: Open
Digital Input Port 3
1
Contents Setting
(0-53)
27
Low oil pressure shutdown. See table 11.
2
Active Type
(0-1)
0
0: Active: Close 1: Active: Open
Digital Input Port 4
1
Contents Setting
(0-53)
0
User defined. See table 11.
2
Active Type
(0-1)
0
0: Active: Close 1: Active: Open
3
Arming
(0-3)
2
0: From safety on; 1: From crank; 2: Always; 3:
Never.
4
Active Actions
(0-2)
0
0: Warning; 1: Shutdown; 2: Indication.
5
Active Delay
(0-20.0)s
2.0
It is time from detecting input port is active to
action confirmation.
6
Input Port
Description
User defined.
Digital Input Port 5
1
Contents Setting
(0-53)
0
User defined. See table 11.
2
Active Type
(0-1)
0
0: Active: Close 1: Active: Open
3
Arming
(0-3)
2
0: From safety on; 1: From crank; 2: Always; 3:
Never.
4
Active Actions
(0-2)
1
0: Warning; 1: Shutdown; 2: Indication.
5
Active Delay
(0-20.0)s
2.0
It is time from detecting input port is active to
action confirmation.
6
Input Port
Description
User defined.
Relay Output Ports
Relay Output Port 1
1
Contents Setting
(0-239)
1
User defined period output 1. See table 10.
2
Active Type
(0-1)
0
0:Normally open; 1:Normally close
Relay Output Port 2
1
Contents Setting
(0-239)
35
Idle speed control. See table 10.
2
Active Type
(0-1)
0
0:Normally open; 1:Normally close
Relay Output Port 3
