APC615 Pump Unit Controller User Manual
APC615 Pump Unit Controller Version 1.0 2017-10-20 Page 27 of 54
No.
Items
Parameter
Default
Description
1
Contents Setting
(0-239)
33
Start relay output. See table 10.
2
Active Type
(0-1)
0
0:Normally open; 1:Normally close
Relay Output Port 4
1
Contents Setting
(0-239)
34
Fuel relay output. See table 10.
2
Active Type
(0-1)
0
0:Normally open; 1:Normally close
Relay Output Port 5
1
Contents Setting
(0-239)
38
ETS control. See table 10.
2
Active Type
(0-1)
0
0:Normally open; 1:Normally close
Relay Output Port 6
1
Contents Setting
(0-239)
48
Common Alarm. See table 10.
2
Active Type
(0-1)
0
0:Normally open; 1:Normally close
Adjust Speed
1
Adjust Speed Type
(0-2)
0
0: Not used; 1: Relay adjust speed; 2: CAN
adjust speed.
2
Output Center:
SW1
(0-10.0)
5.0
Factory default center voltage is 5.0V.
3
Output Range:
SW2
(0-10.0)
2.0
Factory default voltage range is (-2.5~+2.5)V.
4
Speed Gain
(0-1000) %
20
Automatic speed gain control.
5
Speed Control
Stability
(0-1000) %
20
Automatic speed control stability
6
Relay Adjust Speed
Dead
(0-10.0)%
1.0
Relay auto adjust speed control.
7
Speed Adjusting
Relay Gain
(0-100)%
10
8
Speed Adjusting
Relay Stability
(0.05-1.60)s
0.10
9
Speed Adjusting
Relay Response
(0.25-4.00)
0.5
10
Adjust Speed
Stabilized Object
(0-3)
0
0: Outlet pressure; 1: Inlet pressure; 2: Engine
speed; 3: Manual adjust speed.
When the object set as “Inlet pressure”, flexible
sensor 1 is considered as inlet pressure
sensor.
11
Inlet Pressure
Stable Value
(0-2000)kPa
10
When adjust object is inlet pressure, users
need to stabilize the inlet pressure as the
pre-set point.
12
Manual Adjust
Speed Stepping
coefficient
（0-1000）
20
