HAT600N Series ATS Controller User Manual
HAT600N Series ATS Controller Version 1.1 2019-09-05 Page 10 of 24
7. PARAMETERS CONFIGURATION
7.1 PARAMETER SET DESCRIPTION
In the main interface, press key, choose 1.Parameters setting and then press key, to enter
the password interface.
Input password value 0-9 by key, and shift Right by key. Press the again to confirm the
password when four number is OK. If password is correct, it will enter into the parameter main interface.
If it is wrong, it will directly exit and return to main interface. Factory Default Password is 1234. Press
to shift to next position and set the parameters. Under current parameter set screen, press and
enter current parameter set mode. Current value of the first line screen display was highlighted with
black. Press key to change the value and press key to shift position. Press key again to
confirm the settings. If the value number is within the setting range, the value will be saved into the
internal memory of the controller; If it is beyond the range, then the parameter settings will not be saved.
Long time pressing will go back to the main display screen.
7.2 PARAMETER CONFIGURATION TABLE
Table 8 Parameter Configuration Item Table
No.
Item
Range
Default
Description
01
1# Normal Delay
(0-9999)s
10
It is the delay of 1# power from voltage abnormal to
voltage normal.
02
1# Abnormal Delay
(0-9999)s
5
It is the delay of 1# power from voltage normal to
voltage abnormal.
03
2# Normal Delay
(0-9999)s
10
It is the delay of 2# power from voltage abnormal to
voltage normal.
04
2# Abnormal Delay
(0-9999)s
5
It is the delay of 2# power from voltage normal to
voltage abnormal.
05
Close Breaker
(0-20)s
5
Closing relay output pulse. If set as zero, it is
continuous output.
06
Open Breaker
(1-20)s
5
Opening relay output pulse.
07
Transfer Interval
(0-9999)s
1
It is the delay from 1# power open to 2# power
close or from 2# power open to 1# power close.
08
Exceed Transfer
(0-20.0)s
0.0
When module receives a closing signal, closing
relay output.
09
Again Close Time
(0-20.0)s
1.0
When the breaker fail to close for the first time, the
module will open breaker, and then attempt to close
for the second time, if still failed to close the second
time, the module will send out closing breaker
failure signal.
10
Again Open Time
(0-20.0)s
1.0
When the breaker fail to open for the first time, the
module will close breaker, and then attempt to open
for the second time, if still failed to close the second
time, the module will send out opening breaker
failure signal.
11
Start Delay
(0-9999)s
1
When voltage is abnormal, start delay begins and
starting signal is initiated.
In cycle start, starting signal is initiated, delay
begins. After delay ends, if voltage abnormal, send
fault alarm and start another genset. Start delay
should be higher than total starting time, minimum
30 seconds.
12
Stop Delay
(0-9999)s
5
It is the delay from #1 power is normal to send out
stop generator signal.
13
Cycle Run Time
(1-1440)min
720
Gens cycle start run time.
14
Cycle Stop Time
(1-1440)min
720
Gens cycle stop time.
