HAT600N Series ATS Controller User Manual
HAT600N Series ATS Controller Version 1.1 2019-09-05 Page 11 of 24
No.
Item
Range
Default
Description
15
Rated Volt
(100-600)V
230
AC system rated voltage.
16
Over Voltage
(100-150)%
120
The settings are used to configure the power over
voltage point in the event of the voltage rising
above the setting value. This value can be adjusted
to suit user requirements.
17
Over Voltage Return
(100-150)%
115
Normal return value of over voltage.
18
Under voltage
(50-100)%
80
The settings are used to configure the power under
voltage point in the event of the voltage falling
below the setting value.
19
Under Voltage
Return
(50-100)%
85
Normal return value of under voltage.
20
Over Frequency
(0.0-75.0)Hz
55.0
When the frequency is over the point, over
frequency is active.
21
Over Frequency
Return
(0.0-75.0)Hz
52.0
Normal return value of over frequency.
22
Under Frequency
(0.0-75.0)Hz
45.0
When the frequency is under the point, low
frequency is active.
23
Under Frequency
Return
(0.0-75.0)Hz
48.0
Normal return value of over frequency.
24
CT Ratio
(5-65000)/5
500
Current Transformer ratio.
25
Rated Load
Current
(5-6000)A
500
Load rated current.
26
Over Current Value
(50-150)%
120
Load over current value.
27
Over Current Delay
(0-9999)s
1296
Over current alarm delay
28
Module Address
(1-254)
1
RS485 communication address
29
Password
1234
It applies to modify parameters.
30
System Type
(1-4)
1
1.1# Mains 2# Gens
2.1# Gens 2# Mains
3.1# Mains 2# Mains
4.1# Gens 2# Gens
31
Off Position
(1-3)
1
1) two OFF position;
2) one OFF position;
3) no OFF position
32
AC System
(1-4)
1
1. 3-phase 4 wires
2. 3-phase 3 wires
3. Single phase 2 wire
4. 2-phase 3 wires
33
Priority Select
(1-3)
1
1. 1# Priority;
2. 2# Priority;
3. No Priority
34
Aux. Output 1
(1-28)
25
1 Not used
2 Critical failure
3 Fail of Transfer
4 Warning output
5 Alarm output(delay)
6 1# Normal volt
7 1# Abnormal volt
8 2# Normal volt
9 2# Abnormal volt
10 Overcurrent output
11 Auto state output
12 Manual state output
13 Gens Start(N/O)
14 Gens Start(N/C)
15 1# Shut output
16 1# Break Off output
17 2# Shut output
35
Aux. Output 2
(1-28)
28
36
Aux. Output 3
(1-28)
13
37
Aux. Output 4
(1-28)
16
38
Aux. Output 5
(1-28)
18
