HAT600N Series ATS Controller User Manual
HAT600N Series ATS Controller Version 1.1 2019-09-05 Page 12 of 24
No.
Item
Range
Default
Description
18 2# Break Off output
19 Common Alarm output
20 Time Test Gen Start
21 Shut state
22 2# Shut state
23 1# Gens Start(N/O)
24 2# Gens Start(N/O)
25 ATS Power L1
26 ATS Power L2
27 ATS Power L3
28 ATS Power N
39
Aux. Input 1
(1-14)
02
01.Not used
02.Breaking compulsorily
03.Test off-load
04.Test on-load
05. Test Lamp
06. 1# Gens Alarm
07. 2# Gens Alarm
08. Remote start
09. Trip alarm
10. Reserved
11. Reserved
12. Reserved
13. Reserved
14. Reserved
40
Aux. Input 2
(1-14)
01
41
Aux. Input 3
(1-14)
01
42
Aux. Input 4
(1-14)
01
43
Communication Set
(1-4)
1
1.Enable COM Adj/Ctrl
2. Disable COM Control
3. Disable COM Control
4. Disable COM Adg/Ctrl
7.3 INPUT/OUTPUT FUNCTION DESCRIPTION
Table 9 Input Port Function Description
Item
Description
01 Not used
Invalid.
02 Breaking compulsorily
When active, this will force the breaker to transfer the ATS to OFF
position. “None OFF position” ATS is unavailable
03 Test Off-load
When active, controller will send a genset start signal immediately.
When mains is normal, gens will not close the breaker.
04 Test On-Load
When active, controller will send genset start signals immediately.
When gens is normal, gens will close the breaker.
05 Test lamp
When active, all Led lights on the front panel of the controller will be
bright and the background of the LCD will be black in color.
06 1# Gens Alarm
In Cycle start, if the input is active, 1# Gens will not start
07 2# Gens Alarm
In Cycle start, if the input is active, 2# Gens will not start
08 Remote start
This input is necessary for cycle start generator.
09 Trip alarm
10 Reserved
11 Reserved
12 Reserved
13 Reserved
14 Reserved
