HAT600N Series ATS Controller User Manual
HAT600N Series ATS Controller Version 1.1 2019-09-05 Page 5 of 24
Table 2 HAT600N Series Controller Models and Main Functions
Type
DC Power Supply
AC Power Supply
AC Current and Power
HAT600N
√
×
×
HAT600NI
√
×
√
HAT600NB
√
√ (LN220V)
×
HAT600NBI
√
√ (LN220V)
√
3. SPECIFICATION
Table 3 Technical Parameters
Items
Contents
Operating Voltage
DC 8.0V~35.0V, continuous power supply.
HTS220/HWS560 power supply (without battery supply).
AC160V~280V (HAT600NB/HAT600NBI) during AC power L1N1/L2N2 supply.
Power Consumption
<3W (Standby mode: ≤2W)
AC Voltage Input
AC system
HAT600N/HAT600NI
HAT600NB/HAT600NBI
3P4W (L-L)
(80~625)V
(80~480)V
3P3W (L-L)
(80~625)V
Not used
1P2W (L-N)
(50~360)V
(50~280)V
2P3W (A-B)
(80~625)V
(80~480)V
Rated Frequency
50/60Hz
Close / Open Trip
Relay Output
16A AC250V Free Voltage relay output
Programmable
Relay Output
16A/7A AC250V Free Voltage relay output
Digital Input
Connecting to GND
Communication
RS485 isolated interface, ModBus Protocol
Dimensions
209mmx153mmx55mm
Panel Cutout
186mm x 141mm
Operating Temp.
Range
Temperature: (-25~+70)°C; Humidity: (20~93)%RH
Storage Condition
Temperature: (-25~+70)°C
Protection Rank
IP55: when waterproof gasket is installed between enclosure and control screen.
Insulation Strength
Apply AC2.2kV voltage between high voltage terminal and low voltage terminal
and the leakage current is not more than 3mA within 1min.
Weight
0.8kg(HAT600N,HAT600NI)/1.0kg(HAT600NB/HAT600NBI)
