HAT600N Series ATS Controller User Manual
HAT600N Series ATS Controller Version 1.1 2019-09-05 Page 9 of 24
1 Exit
2 Stop to Test
3 Test Off-Load
4 Test On-Load
5 Cycle start
6. COMMISSIONING
In the main screen, press to enter into the operation interface and the screen will show as below:
Press key to select corresponding function, and press key to confirm.
TEST OFF-LOAD: It will send out a start signal immediately. After generator is normal, if mains is normal,
the ATS will not act. The ATS will transfer the load to generator only when mains is abnormal. After
mains return to normal, the ATS will transfer the load to mains. Here the start generator signal output will
keep.
TEST ON-LOAD: It will send out a start generator signal immediately. After generator voltage is normal,
the ATS will transfer the load to gens immediately regardless the main is normal or not.
STOP TO TEST: The start generator signal will turn off after pressing this key immediately.
CYCLE START: When this mode is active, generator start-signal will cyclic output according to mains
status. The cyclic time can be set by users. If generator fault occurs, start-signal won’t be sent out any
more by controller. If in manual mode, controller will keep the current status and cancel cycle start
function.
Conditions and procedures for cycle start mode:
1) In automatic mode.
2) Output setting: 1# engine start output (N/O Output) and 2 # engine start output (N/O Output).
3) Input setting: 1# generator fault input, 2# generator fault input and remote start input.
4) Option of <Cycle run times> and <Cycle shutdown times> should be programmed and run.
5) Set the system type as 1# Gens & 2# Gens.
6) Set the proper <generator start delay> time.
Remark: In manual mode, after choosing commissioning stage, generator will output start-signal immediately, but the
ATS will not transfer to load automatically except for operation manually by pressing key on the front panel.
