HAT600N Series ATS Controller User Manual
HAT600N Series ATS Controller Version 1.1 2019-09-05 Page 13 of 24
Table 10 Output Port Function Descriptions
Item
Description
01. Not used
02. Critical failure
Switch transfer failure also belongs to the critical failure alarm.
03.Fail of transfer
1# closed failure, 1# open failure, 2# closed failure, and 2# open
failure also belongs to the fail to transfer.
04. Warning output
1# reverse phase sequence; 2# reverse phase sequence, and
load over current and compulsory belongs to general warning
output.
05. Alarm output (delay)
When there is Serious fault then it will alarm for 60sec.
06. 1# Normal volt
It will output when 1# voltage is normal.
07. 1# Abnormal volt
It will output when 1# voltage is abnormal.
08. 2# Normal volt
It will output when 2# voltages is normal.
09. 2# Abnormal volt
It will output when 2# voltages is abnormal.
10. Over current output
It will output when loaded current exceeds the limit.
11. Auto state output
In will show output in automatic mode.
12. Manual state output
In will show output in manual mode.
13. Gens start (NO)
When generator starts output (Relay closed).
14. Gens start (NC)
When generator starts output (Relay released).
15. 1# close output
1# Switch ON signal output.
16. 1# open output
1# Switch OFF signal output, for one breaking position breaks off
output.
17. 2# close output
2# Switch ON signal output.
18. 2# open output
2# Switch OFF signal output.
19. Common alarm output
It is include serious fault alarm and common alarm.
20. Timing Start Gen
Schedulers start generator function.
21. 1# Shut state
1# Switch auxiliary shutdown output.
22. 2# Shut state
2# Switch auxiliary shutdown output.
23. 1#Gens start (NO)
1# Gens start output.
24. 2#Gens start (NO)
2# Gens start output.
25. ATS power L1
ATS power supply.
26. ATS power L2
27. ATS power L3
28. ATS power N
