Technical specification
5. Technical specification
Dimensions
490 mm x 430 mm x 440 mm (BxHxT)
Weight 32,2 kg
Connection voltage
100-240 V AC, 50/60 Hz
Power consumption
80 W
Permissible temperature
range
18-30° C
Measureable objects
Plaster model of teeth; plaster colour: white, brown, green
Articulated Models
Minimum clamping range
Diameter 38 mm
Maximum clamping range Diameter 70 mm
Z-adjustmenet range of
object holfer
+/- 40 mm
Measuring time for the
measurement of
Single stump: < 1 min
3-member bridge: < 3 min
Complete jaw: < 5 min
Resolution
Basic resolution of the 3D sensing head: 62,5µm
80 x 60 x 85 (x,y,z)
Accuracy according to
DIN ISO 12836
6 µm
Implant bar accuracy
(following DIN ISO 12836,
messured distance 50.8 mm)
8 µm
Output data format
STL
Interface
USB
Scope of delivery
1. 3D Scanner
2. 1x system base plate
3. 3x spacer plates
4. 1x system adapter plate
5. 1x hex key
6. 1x allen bit set
7. 1x removable object holder
8. 1x power cable
9. 2x USB-cable
10. Software installation CD including calibration data and
Operating manual
11. 1x measuring range template
12. 1x 3D-calibration model
System requirements
Standard PC with CPU 3000 MHz, 4GB RAM, USB interfaces,
500MB free memorey on hard drive, minimum 1 GB GeForce
graphic card, Windows 7 Ultimate, 8.1, 10, all 64 Bit
