Smartoptics Activity 885 - Figure 19: Device Front; Figure 20: Device Rear

26
Basic information about the device
Lid/Ghousing opening
Device designation
Power switch
System drawer
Figure 19: Device front
USB connection for the camera
USB connection for the motor
and scanner control
Fuse
Power cord connection
Functional earth
Figure 20: Device rear
