SMC Networks 6724L2 User Manual

1-1
C HAPTER 1
A BOUT THE
T IGER S WITCH 10/100
Overview
SMC’s TigerSwitch™ 10/100 is a Fast Ethernet switch with 24
10BASE-T/100BASE-TX ports, plus two slots for optional slide-in
100BASE-FX or Gigabit modules. There is also an SNMP-based
management agent embedded on the main board. This agent
supports both in-band and out-of-band access for managing the
switch.
Figure 1-1. SMC6724L2 Front and Rear Panels
Media Slots
1000BASE-LX, 1000BASE-SX,
1000BASE-T or 100BASE-FX modules
System Indicators
Power, SNMP, Console
100-240 V
50-60 Hz 3 A
10/100 Mbps RJ-45 Ports
Mode Selection
Display selection includes:
Collision, activity,
duplex mode, speed
Port Status Indicators
Link - On: link/enable; Off: no link;
Status - Depends on mode selection
Power Socket
Console Port
Use this port for console
or modem connection
Status
Link
Link
Status
Status
M2
M1
FDX
ACT
COL
100M
Power
SNMP
Console
Tiger Switch 10/100
6724L2
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
123 45 67 89101112
13
14
15 16
17
18 19
20
21 22
23
24
M1
M2

SMC Networks 6724L2 Specifications

General

Brand	SMC Networks
Model	6724L2
Category	Switch
Language	English
