C-1
A
PPENDIX
C
S
PECIFICATIONS
Physical Characteristics
Base Unit
Ports
24 10BASE-T/100BASE-TX, with auto-negotiation
2 slots for optional 100BASE-FX or Gigabit modules
Network Interface
10BASE-T: RJ-45 (100-ohm, UTP cable; Categories 3, 4, 5)
100BASE-TX: RJ-45 (100-ohm, UTP cable; Category 5)
Ports 1-24: RJ-45 connectors, auto MDI/MDI-X
Buffer Architecture
1 Mbyte per system
Aggregate Bandwidth
8.8 Gbps
Switching Database
32K MAC address entries
LEDs
System: Power; SNMP, Console
Port:
Link, Status (COL, ACT, FDX, 100M)
Weight
3.74 kg (8 lbs 4 oz)
Size
44.0 x 28.5 x 4.3 cm (17.32 x 11.22 x 1.7 in.)
