SMC Networks 6724L2

C ONSOLE P ORT P IN A SSIGNMENTS
B-7
Console Port to 25-Pin DTE Port on PC
Switch’s 9-Pin
Serial Port
Null Modem PC’s 25-Pin
DTE Port
2 RXD <---------TXD ------------ 2 TXD
3 TXD -----------RXD ----------> 3 RXD
5 SGND -----------SGND ---------- 7 SGND
No other pins are used.
