1000BASE-T Pin Assignments
1000BASE-T ports switch support automatic MDI/MDI-X operation,
so you can use straight-through cables for all network connections
to PCs or servers, or to other switches or hubs.
The table below shows the 1000BASE-T MDI and MDI-X port
pinouts. These ports require that all four pairs of wires be
connected. Note that for 1000BASE-T operation, all four pairs of
wires are used for both transmit and receive.
Use 100-ohm Category 5 or 5e unshielded twisted-pair (UTP) or
shielded twisted-pair (STP) cable for 1000BASE-T connections.
Also be sure that the length of any twisted-pair connection does
not exceed 100 meters (328 feet).
Pin MDI Signal Name MDI-X Signal Name
1 Transmit Data plus (TD1+) Transmit Data plus (TD2 +)
2 Receive Data minus (RD1-) Receive Data minus (RD2-)
3 Transmit Data plus (TD2+) Transmit Data plus (TD1+)
4 Transmit Data plus (TD3+) Transmit Data plus (TD4+)
5 Receive Data minus (RD3-) Receive Data minus (RD4-)
6 Receive Data minus (RD2-) Receive Data minus (RD1-)
7 Transmit Data plus (TD4+) Transmit Data plus (TD3+)
8 Receive Data minus (RD4-) Receive Data minus (RD3-)
