C
ONNECTING
TO
A
P
OWER
S
OURCE
3-7
Connecting to a Power Source
To connect a device to a power source:
1. Insert the power cable plug directly into the receptacle located
at the back of the device.
Figure 3-5. Power Receptacle
2. Plug the other end of the cable into a grounded, 3-pin socket.
Note: For International use, you may need to change the AC line
cord. You must use a line cord set that has been approved
for the receptacle type in your country.
3. Check the front-panel LEDs as the device is powered on to be
sure the Power LED is lit. If not, check that the power cable is
correctly plugged in.
100-240 V
50-60 Hz 2 A
