Alarm 1 can be selected by setting ON
*12
or OFF. The default at
shipping is OFF. In addition, an alarm can be selected from the
following with ON selected.
Lower limit alarm (Lo)
Upper limit alarm (UP)
The default value at shipping is the lower limit alarm (Lo). The
alarm (920) (actuator position range between -20.0 to 120.0%)
can be set. The default value at shipping is (920) = 0.0%.
The setting for alarm 1 will follow the position value (P value).
The input value (S value) will have no influence over the setting.
12: When an alarm is output, which will be indicated on a LCD indicator.
See “■Contents of LCD Display” for detail.
Alarm 2 can be selected by setting ON
*13
or OFF. The default at
shipping is OFF. In addition, an alarm can be selected from the
following with ON selected.
Lower limit alarm (Lo)
Upper limit alarm (UP)
The default value at shipping is the upper limit alarm (UP). The
alarm (A20) (actuator position range between -20.0 to 120.0%)
can be set. The default value at shipping is (A20) = 100.0%.
The setting for alarm 2 will follow the position value (P value).
The input value (S value) will have no influence over the setting.
13: When an alarm is output, which will be indicated on a LCD indicator.
See “■Contents of LCD Display” for detail.
