-27-
No.PS※※-OMM0003-J
■[F 2] Setting of OUT2
Set output method of OUT2.
The display colour is linked to the setting of OUT1, and can not be set for OUT2
<Operation>
Press the
or button in function selection mode to display [F 2].
Press the
button.
Move on to setting output mode.
Set [F 2] based on [F 1] Setting of OUT1 (page 24 to 26).
■[F 3] Response time (chattering prevention function)
Select the response time of the switch output.
Output chattering can be prevented by setting the response time.
<Operation>
Press the
or button in function selection mode to display [F 3].
Press the
button.
Move on to setting of response time.
Press the
button to set.
Return to function selection mode.
Setting of [F 3] Response time completed
Setting of response time
Press the or button to select response time.
